2D LASER CUTTING
ProLaser DYNA
Blazing Dynamics in Laser cutting
The ProLaser Dyna range of laser cutting machines were designed to be no-compromise performers that deliver near maximum performance in all applications and environments. They handle thin sheets at high speed and thick plates at top speeds . Built on a heavy steel base with aluminium composite bridge, the moving elements are simultaneously highly rigid and light for high dynamic performance while maintaining geometry in the cutting process.
Available formats:
| Size | 1.5 m X 3 m |
| Laser powers | 5 kW – 12 kW |
| Dynamics | XY |
| Rapid | 200 m/min |
| Acc | 3 g |
ProLaser MERIT
The work horse laser cutting machine
The ProLaser Merit, the work horse laser cutting machine for a wide variety of laser cutting applications. Rigorous design combined with robust construction has resulted in a field proven machine for job shops and OEM production infrastructures. Excellent balance of features and usability delivers sustained returns for the long term, by keeping investment costs reasonable.
Available formats:
| Size | 1.5 m X 3 m, 2m X 4 m, 2 X 6 m |
| Laser powers | 3 kW, 4 kW, 6 kW , 8 kW |
| Dynamics | XY |
| Rapid | 140 m/min |
| Acc | 1.5 g |
ProLaser SMART
The first step in modern laser cutting
The ProLaser Smart is exactly what it says it is. Smart design, smart ideas and smart manufacturing has resulted in a versatile and cost effective laser cutting machine for every day production for in-house OEM use as well as businesses starting out with their first laser machine. Good for sheet thicknesses upto 16 mm in steel, the versatile machine also handles all kinds of reflective metals with ease.
Available formats:
| Size | 1.25 m X 2.5 m , 1.5m X 3 m |
| Laser powers | 2 kW, 3 kW |
| Dynamics | XY |
| Rapid | 110 m/min |
| Acc | 1 g |
ProLaser MAHA
Large format lasers for thick plate cutting
The ProLaser Maha series are large format laser machines for processing thick materials in sizes larger than 2m width. These are heavy duty lasers built for continuous production of materials upto 35 mm thickness with good cutting finish and precision. Despite the large size and handling capability, the ability to process thin sheets is retained by optional sub-axes that provide the dynamic response for thin sheets. Beam mode control supports this capability further.
Available formats:
| Size | 2.5 m – 3.5 m X 7 m – 24 m |
| Laser powers | 6 kW, 8 kW, 12 kW |
| Dynamics | XY |
| Rapid | 110 m/min |
| Acc | 1 g |
